特征

Use lithium iron phosphate battery cells

Use lithium iron phosphate battery cells

Can be wall mounted or floor mounted

Can be wall mounted or floor mounted

High battery integration and lighter volume

High battery integration and lighter volume

Metal shell

Metal shell

compact in size

compact in size

Faster charge and discharge without memory effect

Faster charge and discharge without memory effect

规格

Battery data

Rated voltage

51.2V

Rated energy

15.46kWh

Nominal capacity

302Ah

Discharge voltage

45~54V

Charge voltage

51.5V~54V

Operating temperature

0℃ ~ 45℃ (Charge)

-20℃ ~ 45℃ (Discharge)

Continuous charge current

200A

Peak charge current

230A

Continuous discharge current

140A

Peak discharge current

230A

Rated discharge power

10000W

Communication protocol

CAN2.0 / RS485


General data

IP protection level

IP31

Extensibility

Support parallel connection (refer to the user manual)

DOD

90%

Lnstallation method

Floor mounted installation

Dimension

980*460*230mm

Weight

120kg

Authentication

UN, CE

Compatible inverter

GoodWe/Deye/Megarevo/Growatt/Lux Power/TBB/Victron/Srne/Must/Senergy/Voltronic /Aotai/Sofar/Sma, etc.


UN38.3、CE、IEC62619

* When the temperature is below 0 ℃ or above 45℃, the performance will be limited.
