特征

Use lithium iron phosphate battery cells

Use lithium iron phosphate battery cells

Can be wall mounted or floor mounted

Can be wall mounted or floor mounted

High battery integration and lighter volume

High battery integration and lighter volume

Metal shell

Metal shell

compact in size

compact in size

Faster charge and discharge without memory effect

Faster charge and discharge without memory effect

规格
Battery data
Rated voltage51.2V
Rated energy14.33kWh
Nominal capacity280Ah
Discharge voltage45~54V
Charge voltage51.5V~54V
Operating temperature0℃ ~ 45℃ (Charge),-20℃ ~ 45℃ (Discharge)
Continuous charge current140A
Peak charge current200A
Continuous discharge current140A
Peak discharge current200A
Rated discharge power7000W
Communication protocolCAN2.0 / RS485


General data
IP protection levelIP31
ExtensibilitySupport parallel connection (refer to the user manual)
DOD90%
Lnstallation methodWall mounted or floor standing
Dimension980*460*240mm
Weight122kg
AuthenticationUN, CE
Compatible inverterGoodWe/Deye/Megarevo/Growatt/Lux Power/TBB/Victron/Srne/Must/Senergy/Voltronic /Aotai/Sofar/Sma, etc.


UN38.3、CE、IEC62619

* When the temperature is below 0 ℃ or above 45℃, the performance will be limited.
