特征

From 5.12 kWh to 30.6 kWh

From 5.12 kWh to 30.6 kWh

Automatically set matching voltage

Automatically set matching voltage

IP65, Support for outdoor use

IP65, Support for outdoor use

Wireless connection/easy installation/more space saving

Wireless connection/easy installation/more space saving

Use lithium iron phosphate battery cells

Use lithium iron phosphate battery cells

Matching with mainstream inverter brands

Matching with mainstream inverter brands

规格
ModelLV M05LV M10LV M15>LV M20LV M25LV M30
Number of modules123456
Nominal capacity100Ah200Ah300Ah400Ah500Ah600Ah
Nominal battery energy>5.12kWh10.2kWh15.3kWh20.4kWh25.5kWh30.6kWh
Maximum continuous discharge power5kW10kW10kW10kW10kW10kW
Maximum continuous charge power5kW10kW10kW10kW10kW10kW
Dimension[W*D*H](mm)700*370*441700*370*609700*370*777700*370*945700*370*1113700*370*1281
Weight73.7kg123.2kg172.7kg222.2kg271.7kg321.2kg
Operating temperature0℃~50℃(Charge) -20℃~55℃ (Discharge)
Provide warranty documentsYes
IP protection levelIP65
ColourWhite
WarnOver charge / Over discharge / Over current / Overheating / Short circuit
AdvantageCan be used for off grid and hybrid settings, compact design, modular expansion
Battery module typeLow voltage
Connection modeParalleling
AuthenticationUN CE ,IEC
Compatible inverterGoodWe/Deye/Megarevo/Growatt/Lux power/TBB/Victron/Srne/Must/Senergy/Voltronic /Aotai/Sofar/Sma, etc.
Communication protocolRS485/CAN
