Modle | ES-233-L | CES-261-L | ||
| DC side parameters | ||||
| Nominal capacity | 280Ah | 314Ah | ||
Number of batteries in series and parallel | 1P552S*5 | |||
Rated energy | 232.960kWh | 261.24kWh | ||
Rated voltage | 832VDC | |||
Voltage range | 728-936VDC | |||
AC side parameters | ||||
| Rated charge current | 87A | |||
Maximum charge current | 174A | |||
Rated discharge current | 87A | |||
Maximum discharge current | 174A | |||
Charge working environment temperature | -30~55℃ | |||
Charge working environment temperature | -30~55℃ | |||
Operating environment temperature | -30~55°C | |||
| General parameters | ||||
| Dimensions | 1335.7*951*2504.2mm | |||
Weight | ≤2.5T | |||
IP protection level | IP54 | |||
Cooling mode | Liquid cooling | |||
oolant | 50% ethylene glycol aqueous solution | |||
Refrigeration capacity | 5.0kw | |||
Cooling input power | 3.2kw | |||
Communication Interface | CAN2.0 / RS485 | |||
Fire level | PACK level fire protection (perfluorohexanone) + water fire protection | |||
