Item | HV U10 | HV U15 | HV U20 | HV U25 | HVU30 |
Module Number | 2 | 3 | 4 | 5 | 6 |
Nominal Voltage | 204.8V | 307.2V | 409.6V | 512.0V | 614.4V |
Nominal Battery Energy | 10.6kWh | 15.9kWh | 21.2kWh | 26.6kWh | 31.9kWh |
Max. Discharge Power | 5kW | 8kW | 12kW | 16kW | 20kW |
Max. Charge Power | 5kW | 8kW | 12kW | 16kW | 20kW |
Dimension[W*D*H] | Defined by the cabinet dimensions | ||||
NetWeight | 103kg | 149kg | 195kg | 241kg | 287kg |
Temp.Range | 0℃ ~ 50℃（Charge） -20℃ ~ 50℃ （Discharge） | ||||
Warranty Letter | Yes | ||||
Ingress Protection | IP21 | ||||
Color | Black | ||||
Alarms | Over Charge / Over Discharge / Over Current / Over Temperature / Short Circuit | ||||
Pros | Can be used in both off-grid and hybrid set ups, compact design | ||||
Battery Module Type | High Voltage | ||||
Module Connection Method | Series | ||||
Compatible Inverters | Deye/Megarevo / Growatt/Keyo/Aiswei, etc. | ||||
